The Unigen Lahitkaya M.2 SSD is designed for energy-efficient computing and high-reliability storage. Built with the SMI SM2259 controller, it serves as a durable, shock-resistant alternative to conventional hard disk drives (HDDs). The Lahitkaya features a proprietary space manager architecture that maximizes data transfer rates between the host and flash memory by eliminating firmware-level delays. Combined with tailored firmware, the SM2259 flash processor provides complete ATA disk emulation, ensuring seamless compatibility with a broad range of legacy and modern operating systems. With a mean time before failure (MTBF) of over 1.75 million hours, these drives are backed by a standard Unigen warranty and dedicated OEM technical support.
Lahitkaya
Features
- M.2 2280 SATA III SSD
- Supports TRIM and SMART
- 3D TLC Toshiba NAND
- P/E cycles: 3,000
- Max. Sequential Read/ Write up to 570/ 510 MB/s
- Random 4Kb Reads/Writes up to 76K/ 74K IOPS
- Capacity 120GB, 240GB, 480GB, 960GB
Specifications
| Appearance | ||
| Weight | up to 90 grams | |
| Form Factor | M.2 | |
| Interface | ||
| Interface | SATA III M.2 2280 | |
| Storage | ||
| Flash Type | TLC, iTLC | |
| Capacity | 120GB, 240GB, 480GB, 960GB | |
| Operating Environment | ||
| Storage Temperature | Operating: 0°C to 70°C (C-Temp) ; Operating: -40°C to 85°C (I-Temp) ; Non-Operating: -40°C to 85°C | |
| Operating Humidity | 5% to 95% , non-condensing | |
| Shock | Operating: 1,000G. Duration 0.5ms, half sine wave | |
| Vibration | Operating: 2.17 gms (5-700 Hz) ; Non-operating: 3.13 gms (5-800 Hz) | |
| Power | ||
| Power Consumption (Max Active) | up to 3600mW | |
| Power Consumption (Idle No ALPM) | up to 1000 mW | |
| Performance | ||
| Sequential Read (max.) | Up to 570 | |
| Sequential Write (max.) | Up to 510 | |
| Mean Time Between Failures | > 1,750,000 hours | |
| Technology | ||
| Power Loss Protection | n/a | |
| DRAM Cache | Yes |
Ordering Information
| Part Number | Capacity |
| UBM2S06120HCD1-HTI-UGN | 120GB |
| UBM2S06240HID1-HTI-UGN | 240GB |
| UBM2S06240HCD1-HTI-UGN | 240GB |
| UBM2S06480HCND1-JKI-UGN | 480GB |
| UBM2S06480HID1-ITI-UGN | 480GB |
| UBM2S06480HIND1-JKI-NTP | 480GB |
| UBM2S06960HCD1-ITI-UGN | 960GB |
